Key Features:
8MP Ultra HD Resolution: Captures high-quality images at 3840 × 2160 resolution.
2.8mm Fixed Lens: Provides a 108° horizontal field of view for wide-area coverage.
EXIR 2.0 Night Vision: Advanced infrared technology offers up to 30 meters (98 feet) of night vision.
120 dB WDR: Ensures clear imaging in high-contrast lighting environments.
Built-In Microphone: Enables real-time audio monitoring for enhanced security.
H.265+ Compression: Efficiently reduces bandwidth and storage requirements without compromising image quality.
IP67 Weatherproof Rating: Designed to withstand harsh outdoor conditions.
On-Board Storage: Supports microSD/SDHC/SDXC cards up to 256 GB.
Technical Specifications:
Image Sensor: 1/2.8" Progressive Scan CMOS
Minimum Illumination: Color: 0.01 Lux @ (F2.0, AGC ON); B/W: 0 Lux with IR
Shutter Speed: 1/3 s to 1/100,000 s
Day & Night: IR cut filter
Angle Adjustment: Pan: 0° to 360°, Tilt: 0° to 75°, Rotate: 0° to 360°
Lens Mount: M12
Aperture: F2.0
DORI Distance: Detect: 81 m; Observe: 32 m; Recognize: 16 m; Identify: 8 m
IR Wavelength: 850 nm
Video Compression: Main stream: H.265+/H.264+/H.265/H.264; Sub-stream: H.265/H.264/MJPEG
Video Bit Rate: 32 Kbps to 16 Mbps
Audio Compression: G.711ulaw/G.711alaw/G.722.1/G.726/MP2L2/PCM/AAC
Audio Bit Rate: 64 Kbps (G.711 ulaw/alaw); 16 Kbps (G.722.1/G.726); 32–160 Kbps (MP2L2); 16–64 Kbps (AAC)
Audio Sampling Rate: 8 kHz/16 kHz
Network Interface: 1 RJ45 10M/100M Ethernet port
Power Supply: 12 VDC ± 25% or PoE (802.3af)
Power Consumption: Max. 7.5 W
Operating Conditions: -30°C to 60°C (-22°F to 140°F); Humidity 95% or less (non-condensing)
Dimensions: Ø127.3 mm × 95.9 mm (Ø5.01" × 3.78")
Weight: Approx. 600 g (1.32 lbs)
